Quick Details

  • Condition: New
  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Fanshun
  • Model Number: GYT-500
  • After-sales Service Provided: Engineers available to service machinery overseas
  • Usage: honey brass turnkey project
  • Finished products: brass billet,brass fittings, valves
  • Working voltage: 380v/50hz
  • Raw material: copper calbe, brass honey

Packaging & Delivery

Packaging Details: Wooden pallet packaged
Delivery Detail: Within 60 days after T/T or L/C

Specifications

1 honey brass recyling turnkey plant
2 machinery and technique support supplier
3 low budget, environment friendly

 honey brass recycling turnkey plant


                                                                                                       honey brass



Introduction and structure

Melting furnace and holding furnace are tied together. No smoke furnace itself while melting. Auto constant temp control unit is available. Widely used in  the field of brass, copper alloy products.

Both furnace connect through bottom, raw material melted down, liquid can be flowed to holding furnace chamber after component of liquid met special requirement. We this design structure can reduce smoke, loss of zinc because of oxidizing. Energy consumption is less.

The 120kw, 75kw main frequency cored induction furnace is composed by furnace body, inductor, cabinet, the inductor is installed under furnace body, include iron core, copper loop, coil, water jacket and so on.



1  75kw melting furnace + 75kw holding furnace

 Specification:

 Model: 300

 Power: 75+75(kw)

 Melting rate: 300kg/h

 Capacity: 1+1.8(ton)

 Quantity: 1 unit



2 Die casting machine

Specification:

Model: SYO-60

Speed: 0-0.035m/s

Casting diameter: 5-60mm

Quantity: 2 set





3 Pneumatic sawing machine

Specification:

Model: Q60

Cutting size: Φ5-60mm

Speed: 10s/pcs

Power: 3kw

Air pressure: 0-1 Mpa

Quantity: 2 set



4 Heading machine

Specification:

Model: CZ-A

Heading size: Φ5-20mm

Heading length: 50-120mm

Cutter: 4 set

Motor power: 2.2kw

Quantity: 1 set



5 Heading machine

Specification:

Model: CZ-C

Heading size: Φ15-60mm

Heading length: 50-120mm

Cutter: 4 set

Motor power: 4kw

Quantity: 1 set





6 Chain type double peeling machine

 Specification:

 Model: LG-250(A)(B)

 Peeling size: Φ5-15mm

 Working length: 3m

 Speed: 0.4m/s

 Power: 5.5kw

 Quantity: 1 set





7 Peeling machine

 Specification:

 Model: 5T

 Peeling size: Φ15-60mm

 Working length: 3m

 Speed: 15-25m/min

 Power: 18.5kw

 Quantity: 1 set





8 Hexagon straightening machine

 Specification:

  Model: YT-11C

  Straightening size: S10-40mm

  Precision: 0.2mm/100mm

  Motor power: 5.5

  Quantity: 1 set



9 Hexagon straightening machine

 Specification:

  Model: YT-11D

  Straightening size: S40-60mm

  Precision: 0.2mm/100mm

  Motor power: 7.5 kw

  Quantity: 1 set





 Machining procession solutions below:

Item

specification

quality

Brass rod auto

slicing machine

Ø8-45mm

one set

Heating furnace(kerosine powered )



One unit

Hot forging machine

125T

One set

Mold bracket(main)









1/2" valve

One set

Mold core(main)



One set

Trimming mold(main)



One set

Spare parts



Mold bracket(brass nut)



One set

Mold core(brass nut)



One set



Hot forging machine

40T

One set

Mold core



 3/4" valve

One set

Trimming mold



One set

Mold core(brass nut)



One set

Sanding machine



One set

CNC lathe



Two set

brass rod CNC lathe



Two set

Milling machine(core)



Two set

Assembling line(4-6 person)



One set

inspection unit



Two set

Packing line



One set





 Related pictures



              2 melting  furnace,holding furnace                          3 polishing machine

                  4 straightening machine                                             6 CNC lathe                                            7 plating





                                                                                                        5 forging press





Finished products:
